Evolis Primacy Card printers

ThePrimacy printer is ultra-fast, powerful, and efficient. Using advanced encodingtechnologies, this office printer is the ideal solution for printingpersonalized cards, from the simplest to the most secure.

Availableas single or double-sided, Primacy especially meets card printing and encodingneeds for medium and large runs.

Primacyis ideal for producing:

Transporttickets

Paymentcards

NationalID cards

Studentcards

Employeebadges

Eco-design

Aspart of its eco-design approach which aims to reduce the environmental the footprint of its products, Evolis:

Prioritizesthe use of recycled materials in the manufacturing of its printers andconsumables,

Designscompact and light printers to reduce CO2 emissions related to transport andpackaging,

Reducesthe electrical consumption of its printers with a highly efficient prolongedstandby mode.

General features

direct-to-card dye-sublimation/Resin thermal transfer

Single-sided printing, edge-to-edge

Standard 300 x 300 dpi resolution

Customizable 300 x 600 dpi resolution (color and monochrome printing) or 300 x 1200 dpi resolution (monochrome printing only)

Colors available: fire red & brilliant blue

Dual-sided Card Lamination Module (CLM) as an option1

32 MB memory (RAM) standard - optional 64 MB1

Printingperformances1

Single side:

Color (YMCKO): 190 - 225 cards/hour

Monochrome: 800 - 1000 cards/hour

Dual side:

Color (YMCKO-K): 140 cards/hour

Interfaces

USB (1.0, 1.1, 2.0, 3.0), cable supplied

Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)

802.11b/g wireless connection on the Wireless range

Cards-management and specifications

Feeder capacity: 100 cards (0.76 mm  30 mil)

Output hopper capacity: 100 cards (0.76 mm  30 mil)

Open output hopper as an option for collecting cards one by one

Reject tray/output hopper capacity at the back: 50 cards(0.76 mm  30 mil)

Card thickness: 0.25 to 1.25 mm (10 to 50 mil), gauge-adjustment (0.25 mm - 10 mil only for monochrome printing)

Card types: PVC cards, Composite PVC cards, PET cards, ABScards1, specially varnished cards1

Card format: ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)

Additional encoding modules

Available modules:

Magnetic-stripe encoder ISO 7811 HiCo/LoCo, JIS2

Smart contact station ISO 7816-2

Contact smart card encoder - PC/SC, EMV 2000-1

Contact less smart card encoder - ISO 14443A, B, ISO15693, MIFARE, DESFire, HID iCLASS, UHF(standard compliance: EPC C1 Gen2 / ISO18000-6C ETSI EN 302 208 or FCC part15.247)

Other specific encoders upon request

InternalUSB or IP ports

USBencoding over IP through additional USB Net Server module, upon request

Option scan be combined

Factory-installed installed on site

Safety

Support for Kensington® security lock

Data encryption for magnetic encoding1

The locking system as an option1

Display

PrinterLEDs

Color-touch screen as an option

Graphical-notifications from the printer2: cleaning alerts, empty/low-level ribbon and card alerts, etc.

Evolis HighTrust® Ribbon

Automatic identification and setting

Delivered in a drop-in cassette for easy handling

Ribbon saver for monochrome printing

Software

Delivered with Evolis Premium Suite® for Windows®:

Printer driver

EvolisPrint Center for administration and settings

24/7online support

Compatible with Windows® (32/64 bits): XP SP3, Vista, W7, W8, W10

Delivered with cardPresso XXS for designing and editing badges:

Internal database (unlimited records)

Windows®(from XP onwards) and Mac OS X

Delivered with a driver for Mac OS X (from 10.6 onwards)

Linux upon request

EvolisPremium SDK for remote supervision of the printer, while facilitating and speeding up integration into IT systems

Eco-friendly design, certifications, and statement of compliance

Standby, sleep modes & reduced energy consumption

CE, FCC, ICES, VCCI, CCC, KC, BIS, EAC

RoHS

Size and weight

Size (H x W x D):

247 x 205 x 381 mm (9.72x 8.07 x 14.99)

With reject tray/output hopper at the back:

247 x 205 x 487 mm (9.72 x 8.07 x 19.17)

Weight: 4.02 kg (8.86 lbs)

With reject tray/output hopper at the back:

4.11 kg (9.06 lbs)
