Honeywell SG20 Barcode Scanner in Jessor
Important hospital verification processes need not impact productivity. Minimize the time and effort to read barcodes with a speedy SG20 healthcare barcode scanner.
Interested in this product?
Request a quote
Tell us the quantity and delivery city, and we'll reply within working hours.
- CategoryHandheld Barcode Scanners
- BrandHoneywell
- AvailabilityIn stock, ships fast
- Sourced through authorised channels
- Set-up & service by our engineers
- Shipped anywhere in India
Important hospital verification processes need not impact productivity. Minimize the time and effort to read barcodes with a speedy SG20 healthcare barcode scanner. Designed with ergonomics and the hospital environment in mind, the SG20 healthcare scanner features a housing made of disinfectant-ready materials.
The SG20 Healthcare Scanner is an affordable, high-performance handheld scanner available in tethered or cordless models. It's built to excel in the hospital and help ensure your clinicians meet patient safety standards. The SG20 scanner features speedy omnidirectional 2D barcode reading technology and more motion tolerance than competing devices. This ensures you can scan all common 1D and 2D barcodes easily and consistently, at any orientation, and without the need to reposition items or disturb resting patients. We understand that a one-size-fits-all approach to healthcare scanning can limit user efficiency and accuracy. So the SG20 family includes the option of either a Bluetooth® wireless or wired scanner, and a choice between high-performance scan engines with laser or LED aimers perfect for patient-facing applications. This flexibility makes it possible to standardize on a single scanner family across your healthcare operation while providing just the right model for your exact needs. A variety of matching accessories, such as scanner stands, enable hands-free scanning and free up much-needed counter or workstation-on-wheels. Regardless of the configuration, the entire SG20 line is priced for affordability and value.
MECHANICAL
Dimensions (LxWxH)
20 cm x 6.1 cm x 6.5 cm (7.9 in x 2.4 in x 2.6 in)
Weight
SG20T: 125 g (4.41 oz) ; SG20B: 175 g (6.17 oz)
ELECTRICAL
Battery
Type: Lithium-ion rechargeable (1567 mAh)
Battery Life: 8K scans from 70% capacity
Battery Recharge Cycle: 3 hours when connected to external power supply; 6 hours when slow charged from typical USB port
Operating Power
Tethered (Corded) Versions @5V DC: 330mA
Wireless Versions (Base Station): 0.5A maximum
Host System Interfaces
USB: HID Keyboard (with Apple® iOS Support), HID POS*, IBM SurePOS (Tethered -corded- versions), virtual communications port; PC keyboard wedge; RS-232
BLUETOOTH
Type: Bluetooth Class 2 v2.1+EDR
Range: 10 m (32.8 ft)
Features: Adaptive Frequency Hopping (AFH)
ENVIRONMENTAL
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
5% to 95% non-condensing
Drop
1 m (3.4 ft) to concrete
Environmental Sealing
IP30
Light Levels
0 to 100,000 lux
APPROVALS
ELECTROMAGNETIC EMISSIONS
Meets the requirements of the following product emission standards: United States: FCC Part 15 Class B
European Union: EN 55022: CISPR 22 Class B
ENVIRONMENTAL COMPLIANCE
Conforms to environmental compliance requirements for RoHS, China RoHS, WEEE and REACH
APPROVED DISINFECTANTS
CaviCide (Metrex); CidexPlus (Johnson & Johnson); Clorox; MadaCide-1 (MadaMedicalProduct); Super Sani-Cloth (PDI); Viraguard
(Veridien)
INDUSTRY APPROVALS
Healthcare: Cerner (Certified), McKesson (Certified)
REGULATORY APPROVALS
UL; CE Mark (EU); NOM (Mexico); C-TICK (Australia and New Zealand); SRRS (China); IDA (Singapore); ANATEL (Brazil); Industry Canada ICES-003 Class B (Canada)
SCAN PERFORMANCE
Scan PatternHoneywell Area Imager, Laser Aimer (EA30) Honeywell Area Imager, LED Aimer (EA31)
Motion ToleranceSG20xHP: 12.7 m/s (500 in) SG20x2D: 10.16 m/s (400 in)
Symbol Contrast
20%Image Resolution
1D Codes: 4 mils 2D Codes: 6.6 mils
BARCODE SYMBOLOGIES SUPPORTED
1D: Codabar, Code 11, Code 39, Code 93/93i, Code 128 / GS1-128, EAN/UPC, GS1 DataBar Limited, GS1 Composite (linear only),
GS1 DataBar Expanded, GS1 DataBar Omnidirectional, Interleaved 2 of 5, Matrix 2 of 5, MSI, Plessey, Standard 2 of 5,
Telepen
2D: Australian Post, Aztec, BPO, Canada Post, Codablock A, Codablock F, DataMatrix, Dutch Post, EAN/UPC, GS1 Composite, GS1
DataBar Stacked, Infomail, Intelligent Mail, Japan Post, Maxicode, Micro PDF417, Multicode, PDF417, Planet, Postnet, QR Code, Sweden Post, TLC 39
Warranty
Tethered Models (SG20T): 5 years
Wireless Models (SG20B): 3 years
Dimensions (LxWxH)
20 cm x 6.1 cm x 6.5 cm (7.9 in x 2.4 in x 2.6 in)
Weight
SG20T: 125 g (4.41 oz) ; SG20B: 175 g (6.17 oz)
ELECTRICAL
Battery
Type: Lithium-ion rechargeable (1567 mAh)
Battery Life: 8K scans from 70% capacity
Battery Recharge Cycle: 3 hours when connected to external power supply; 6 hours when slow charged from typical USB port
Operating Power
Tethered (Corded) Versions @5V DC: 330mA
Wireless Versions (Base Station): 0.5A maximum
Host System Interfaces
USB: HID Keyboard (with Apple® iOS Support), HID POS*, IBM SurePOS (Tethered -corded- versions), virtual communications port; PC keyboard wedge; RS-232
BLUETOOTH
Type: Bluetooth Class 2 v2.1+EDR
Range: 10 m (32.8 ft)
Features: Adaptive Frequency Hopping (AFH)
ENVIRONMENTAL
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
5% to 95% non-condensing
Drop
1 m (3.4 ft) to concrete
Environmental Sealing
IP30
Light Levels
0 to 100,000 lux
APPROVALS
ELECTROMAGNETIC EMISSIONS
Meets the requirements of the following product emission standards: United States: FCC Part 15 Class B
European Union: EN 55022: CISPR 22 Class B
ENVIRONMENTAL COMPLIANCE
Conforms to environmental compliance requirements for RoHS, China RoHS, WEEE and REACH
APPROVED DISINFECTANTS
CaviCide (Metrex); CidexPlus (Johnson & Johnson); Clorox; MadaCide-1 (MadaMedicalProduct); Super Sani-Cloth (PDI); Viraguard
(Veridien)
INDUSTRY APPROVALS
Healthcare: Cerner (Certified), McKesson (Certified)
REGULATORY APPROVALS
UL; CE Mark (EU); NOM (Mexico); C-TICK (Australia and New Zealand); SRRS (China); IDA (Singapore); ANATEL (Brazil); Industry Canada ICES-003 Class B (Canada)
SCAN PERFORMANCE
Scan PatternHoneywell Area Imager, Laser Aimer (EA30) Honeywell Area Imager, LED Aimer (EA31)
Motion ToleranceSG20xHP: 12.7 m/s (500 in) SG20x2D: 10.16 m/s (400 in)
Symbol Contrast
20%Image Resolution
1D Codes: 4 mils 2D Codes: 6.6 mils
BARCODE SYMBOLOGIES SUPPORTED
1D: Codabar, Code 11, Code 39, Code 93/93i, Code 128 / GS1-128, EAN/UPC, GS1 DataBar Limited, GS1 Composite (linear only),
GS1 DataBar Expanded, GS1 DataBar Omnidirectional, Interleaved 2 of 5, Matrix 2 of 5, MSI, Plessey, Standard 2 of 5,
Telepen
2D: Australian Post, Aztec, BPO, Canada Post, Codablock A, Codablock F, DataMatrix, Dutch Post, EAN/UPC, GS1 Composite, GS1
DataBar Stacked, Infomail, Intelligent Mail, Japan Post, Maxicode, Micro PDF417, Multicode, PDF417, Planet, Postnet, QR Code, Sweden Post, TLC 39
Warranty
Tethered Models (SG20T): 5 years
Wireless Models (SG20B): 3 years
